| 典型型號 Model | LT1 5-350 | LT17-350 | LT1 7-250 | LT19-250 | LT19-200 | LT21-200 |
| 卷筒直徑 Capstan diameter | 350 | 350 | 250 | 250 | 200 | 200 |
| 拉拔道次 Drawing passes | 15 | 17 | 17 | 19 | 19 | 21 |
| 進線強度（Mpa) Inlet line intensity | ≤1250 | ≤1250 | ≤1250 | ≤1250 | ≤1250 | ≤1250 |
| ******進線直徑 Max. Inlet size diameter | 3.2-2.2 | 3.2-2.2 | 1.8-1.6 | 1.8-1.6 | 1.5-1.2 | 1.5-1.2 |
| 最小出線直徑 Min.Outlet size diameter | 1.0-0.6 | 0.8-0.5 | 0.52 | 0.5-0.4 | 0.34-0.28 | 0.3-0.23 |
| 總壓縮率 （％) Gross compression rate | 92.56 | 92.84 | 91.65 | 93.75 | 94.79 | 96.18 |
| 平均壓縮率 （％) Average compression rate | 14.37 | 14.37 | 13.59 | 13.58 | 14.4 | 14.4 |
| 拉拔速度(m/min) Drawing speed | 420 | 420 | 480 | 420 | 600 | 600 |
| 電機功率（Kw) Motor power | 37-45 | 37-45 | 22-37 | 22-37 | 18.5-22 | 18.5-22 |
| 外形尺寸 External dimensions | 3000x1500x1350 | 2500x2050x1350 | 2000x1600x1350 | |||
| 重量 （t） Weight | 3.5 | 3.5 | 2.8 | 2.8 | 2.2 | 2.2 |
| 拖動方式 Drag way | 變頻 | |||||
| 備注 ： | 拉拔道次、卷筒直徑、有關參數可根據用戶要求定制 | |||||
